ELECTRICAL PARAMETERS
Accuracy: 0.05%, 0.02%
Power Supply: One Phase AC 180-265V, frequency 50/60Hz.
DC Voltage measurement
Range: 10mV, 100mV, 1V, 10V, 30V, 100V, 300V, 1000V (max
1200V)
Accuracy: ±(0.012%RD+0.008%RG)
DC Current measurement
Range: 0.7mA, 3.5mA, 14mA, 35mA, 140mA, 700mA, 1A, 2A, 5A,
10A, 20A, 50A, 100A, 500A (max 600A)
small signal 2.5mV, 20mV, 100mV, 1V, 5V
Accuracy: ±(0.012%RD+0.008%RG)
DC Power measurement
power accuracy: ±0.02%
DC Power Energy Measurement Error
power energy: ±0.02%
Power Pulse Output
Power Pulse Output: 20KHz
Power Pulse Input
Energy pulse input: 20KHz
Communication port: USB port, RS232, 10/100M LAN
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 400x440x290
Weight (kg): 12
ENVIRONMENTAL CONDITIONS
Ambient temperature: -10°C ~ +40°C
Relative humidity: 35% ~ 38%
