ELECTRICAL PARAMETERS
Accuracy class: 0.05%, 0.1%
Power supply: Single phase AC 220V±10% or 110V±10%, 50/60Hz
Communication port: USB, RS232
AC Voltage output
Range(U1,U2,U3): 50V, 100V, 200V, 400V, 600V
Adjusting range: (0-120)% RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01% / 1 min
Load capacity: 25VA
Output distortion degree: ≤0.3% or (linear load)
AC Current output
Range(I1,I2,I3): 0.5A, 1A, 2.5A, 5A, 10A, 20A
Adjusting range: (0-120)% RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1 min
Load capacity: 25VA
Output distortion degree: ≤0.3% or (linear load)
AC Power output
Accuracy: 0.05% RG
Stability: 0.01%/1min
Frequency
Frequency range: 45.000 - 65.000 Hz
Resolution: 0.001 Hz
Accuracy: 0.002 Hz
Power factor output
Adjusting range: -1 ~ 0 ~ 1
Adjust fineness: 0.0001
Accuracy: 0.0005
Phase angle
Scope: 0°-359.99°
Resolution: 0.01°
Accuracy: 0.05°
Voltage/Current harmonic output
Times: 2-31st
Content: 0-40%
Phase: 0-359.999 degree
Configuration error: (10% RD + 0.1%), RD refers to the configuration value of harmonic contents
DC Voltage output
Range: 75mV, 75V, 150V, 300V, 500V, 1000V
Adjusting range: (0-120)% RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25VA
DC Current output
Range: 0.5A, 1A, 2.5A, 5A, 10A, 20A
Adjusting range: (0-120)% RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25VA
DC measurements
DC voltage measurement range: 0 to ±24V
DC current measurement range: 0 to ±24mA
Measurement accuracy: 0.01% RG
Watt-hour meter measuring the integrated error
Active energy: 0.05%
Reactive energy: 0.1%
MECHANICAL PARAMETERS
Dimensions (W×H×D) (mm): 460x430x185
Weight (kg): 20
ENVIRONMENTAL CONDITIONS
Working temperature: 0°C to 40°C
Storage conditions: -30°C to 60°C
Relative humidity: ≤85%
