ELECTRICAL PARAMETERS
Accuracy: 0.05%
Power Supply: One Phase AC 180-265V, frequency 50/60Hz.
DC voltage output
Range: 65V, 250V, 500V, 750V, 1000V (max 1150V)
Adjustment range: (0-120)%RG(1)
Adjustment fineness: 0.01%RG, 0.1%RG, 1%RG, 10%RG as
optional.
Stability: 0.01%/120s
Distortion: 0.1% (Non-capacitive load)
Output load: 50VA
Full load regulation rate: ≤±0.01%RG
Accuracy: ±(0.03%RD+0.02%RG)
DC current output
Range: 0.001A, 0.005A, 0.02A, 0.05A, 0.2A, 1A, 3A, 10A, 20A,
50A, 100A, 500A (max 600A)
small signal 2.5mV, 20mV, 100mV, 1V, 5V
Adjustment range: (0-120)%RG
Adjustment fineness: 0.01%RG, 0.1%RG, 1%RG, 10%RG as
optional.
Stability: <0.01%/120s, small signal 2uV/min
Distortion: ≤0.1% (Non-capacitive load)
Output load: 1200VA
Full load regulation rate: ≤±0.01%RG
Accuracy: ±(0.03%RD+0.02%RG)
Externally attached shunt: 100mV
Accuracy: ±(0.06%RD+0.04%RG)
DC Power Output
power output stability: <0.01%RG/120s
power accuracy: ±(0.03%RD+0.02%RG)
DC Power Energy Measurement Error
power energy: ±(0.03%RD+0.02%RG)
Power Pulse Output
Power Pulse Output: 20KHz (Full-Range)
Power Pulse Input
Energy pulse input: 20KHz
Ripple output: 20-500Hz ripple output
Communication port: USB port, RS232, 10/100M LAN
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 630x600x450
Weight (kg): 20,55
ENVIRONMENTAL CONDITIONS
Ambient temperature: -10°C ~ +40°C
Relative humidity: -30°C ~ 60°C
