BAISC PARAMETERS
CPU: ARM32 CPU 132MHz (SAMSUNG)
Operation system: TPOS
RAM: 512K
ROM: 2M
Flash: 64M Flash
Display: 3.2 inch display, 160x160 pixel
Real time: Much less than 0.5 seconds every day under common
temperature
Keypad: 20 keypads
Non-slip function: Non-slip handle design, the battery back
can locked to prevent battery cover lost
Power off protection: Using flash technology, the data is
still safe preservation after power off
Control instruction: ESC/POS compatible instruction sets
Communication ports: RS232, IR, USB2.0
Optional configuration: IR
Battery: High capacity rechargeable of lithium battery
Programming language: C language, DBF database development
system
Seiko printer
paper diameter: 40mm
The maximum width of the printing paper: 58mm
The maximum width can be printed: 48mm
Print method: Thermal line printing
Resolution: 8 dots/mm (203dpi)
The count of every line: 384 dots，every line can print 16 Chinese
characters or 32 characters
Print contents: Chinese, Number, English, Graphics, Curve,
Barcode
Print speed: 45mm/s
MECHANICAL PARAMETERS
Dimensions (LxWxH) (mm): 195×65×45
Weight (g): About 256 (not including battery)
ENVIRONMENTAL CONDITIONS
Work temperature: -5°C ~ 50°C
Storage
temperature: -25°C ~ 70°C
