Output Parameters:
+ Max Output Power: 105 W
+ Number of Outputs: 2 independent & electrically isolated outputs
+ Range: Variable: 0-30 VDC / 0-3 A
Fixed: 5 V / 3 A
Load Regulation:
+ CC Mode: <15 mA
+ CV Mode: ±0.05% + 32 mV
+ Fixed 5 V Output: <70 mV
Line Regulation:
+ CC Mode: ±0.05% + 2 mA
+ CV Mode: ±0.05% + 2 mV
+ Fixed 5 V Output: <5 mV
Ripple & Noise:
+ CC Mode: <2.5 mArms
+ CV Mode: <0.4 mVrms
+ Fixed 5 V Output: <1.5 mVrms
Display Accuracy:
+ Voltage & Current: 0.1% + 2 digits
+ Fixed 5 V Output: ± 0.25 V
Gerneral
+ AC Input: VAC 115/230 ± 10%, 50/60 Hz
+ Operating Temperature: 50°F to 104°F (10°C to 40°C)
+ Operating Humidity: 90% R.H.
+ Dimensions (W x H x D): 9 x 6.7 x 12.2 in (230 x 170 x 310 mm)
+ Weight: 13.3 Ibs (6.0 kg)
