DC VOLTAGE
Range: 60.00mV, 600.0mV, 6.000V, 60.00V, 600.0V, 1000V
Best Accuracy: ±(0.5%rdg + 3 digits)
Input Impedance: 10 MΩ (At mV range : 1GΩ)
AC VOLTAGE
Range: 60.00mV, 600.0mV, 6.000V, 60.00V, 600.0V, 1000V
Best Accuracy: ±(1.0%rdg + 3 digits)
Frequency Response: 40Hz-1kHz
Input Impedance: 10 MΩ
DC CURRENT
Range: 600.0µA,
6000µA, 60.00mA, 600.0mA, 6.000A, 20.00A
Best Accuracy: ±(1.0%rdg + 2 digits)
AC CURRENT
Range: 600.0µA, 6000µA, 60.00mA, 600.0mA, 6.000A, 20.00A
Best Accuracy: ±(1.2%rdg + 5 digits)
RESISTANCE
Range: 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ, 60.00MΩ
Best Accuracy: ±(1.0%rdg + 2 digit)
CONTINUITY BEEPER
Buzzer sounds if conductance less than 50Ω
DIODE TEST
Open Circuit Voltage: 3V (Approx.)
CAPACITANCE
Range: 60.00nF, 600.0nF, 6.000µF, 60.00µF, 600.0µF, 6.000mF,
60.00mF
Best Accuracy: ±(3.0%rdg + 5 digits)
FREQUENCY
Range: 10Hz ~ 10MHz
Best Accuracy: ±(0.1% rdg + 4 digits)
TEMPERATURE
Range: -40ºC ~ 1000ºC / -40ºF ~ 1832ºF
Best Accuracy: ±(1.0%rdg + 3 ºC); ±(1.0%rdg + 4 ºF);
SPECIAL FUNCTION
Auto Ranging; True RMS; Analog Bar; USB
Display Backlight, NCV Function; Audible / Visual Alarm
LoZ ACV
LCD DISPLAY
6000 counts
POWER SOURCE
1.5V AAA x 4
DIMENSIONS & WEIGHT
89(W) x 186(H) x 49(D) mm, Approx. 400g
ACCESSORIES
USB cable & Adapter socket, Battery, User manual, Test leads, K-type thermocouple
