Applications: Azimuth, Missing Line (Distance Between Two Remote Points), Slope Distance, Horizontal Distance, Height, Actual Distance, Angle, Vertical Separation, Three-point Measurement (Height Between Two Points)
General
Weight: 243 g/8.6oz.
Color: Orange
Dimensions: 93x63x72mm/3.7x2.5x2.8”
Protection Class: MIL-STD-810E. Housing frame material glass filled poly carbonate, IP67, NEMA6, Laser class 1, 7mm (FDA, CFR21) Class 1m (IEC 60825-1:2001).
Operating Temperature: -20° to +45° C/ -4°F-113°F
Units of Measure: Metric or Inch
Laser Classification: class 1, 7mm (FDA, CFR21) Class 1m (IEC 60825-1:2001)
Accuracy
Distance to Near Targets: ±0.1-foot
Inclination: 0.10 typical
Azimuth: 0-360 °, resolution 0,1 °, accuracy <1.5 RSME °.
Range
Maximum: 999 m/ft
Minimum: 0 m/ft
Angle: -90° - 90°
Battery/Power
Power Source: Li-ion battery (built-in)
Display/Finder
Type: External Graphic LCD 100x60pixles. Internal Heads-up display
Backlight: Yes
Communication
Bluetooth: Yes
Features
Tilt-Sensor (Inclinometer): Yes
