Power consumption: 410W (Max.)
Temperature range:
FM-2027: 200 to 450ºC
FM-2029: 100 to 550ºC
Temperature stability: ±5ºC at idle temperature
・Station
Output voltage: AC 24V
Vacuum generator: Vacuum pump, cylinder type
Vacuum pressure: 80kPa (600mmHg) (Max.)
Suction flow: 14L/min.
Air flow: 6L/min. (Max.)
Dimensions: 162(W)×136(H)×245(D)mm
Weight: 6.2kg
・Soldering Iron (FM-2027)
Power consumption: 70W (24V)
Tip to ground resistance: <2Ω
Tip to ground potential: <2mV
Heating element: Composite heater
Cord length: 1.2m
Total length: 188mm (with 2.4D tip)
Weight: 30g (with 2.4D tip)
・Desoldering Tool (FM-2024)
Power consumption: 70W (24V)
Nozzle to ground resistance: <2Ω
Nozzle to ground potential: <2mV
Heating element: Composite heater
Cord length: 1.2m
Total length: 180mm (with Φ1.0mm nozzle)
Weight: 65g (with Φ1.0mm nozzle)
・Hot air Handpiece (FM-2029)
Power consumption: 140W (24V)
Nozzle to ground resistance: <2Ω
Nozzle to ground potential: <2mV
Heating element: Composite heater
Cord length: 1.2m
Total length: 232mm (with Φ4.0mm nozzle)
Weight: 50g (with Φ4.0mm nozzle)
Packing List: Station, Power cord, FM-2024 conversion kit, Tip tray, FM-2027 conversion kit, FM-2029 conversion kit, Instruction manual
