Working Voltage Range: AC 50V ~ 600V 50/60Hz
Insulation Resistance: Between contact tip and clip (grip): 100ΜΩ minimum with a 500V megger
Dielectric Strength: Ditto:2000V-1 minute
Leakage Current: Ditto: 100µA maximum
Impulse Withstand: Ditto:8000V-10 cycles of positive/negative (IEC61010-1 CAT III 1000V equivalent)
Operation Starting Voltage (Voltage to ground)
Maximum sensitivity: AC40V maximum
Minimum sensitivity: Not operation at AC100V
Operation at AC200V
Operation Status Display
Light: Intermittent red light visible in 8000lx ambient
Sound: Intermittent sound of 50dB minimum in 30cm distance
Operating Temperature Range: 0°C ~ +40°C
Weight: 22g(including batteries)
Battery: 2 alkaline button cells LR44(1.5V)
Life of the battery: New battery: in continuous operation 10 hours ( with LED Lamp off) / 5 hours ( with LED Lamp on): in storage 1.5 years
