X-ray angle: 0° only
Tunnel size: 400(W)×300(H)mm
Belt width: 460mm
Belt speed: Adjustable Belt Speed 15～25m/min
Object weight: Max5kg
X-ray sensor: Straight Type Line Sensor
Sensor length: 409.6mm
Sensor pixel size: 0.4mm
Sensor pixel number: 1024pixels
X-ray Tube Voltage: 30～75kV
X-ray Tube Current: 0～3mA
OS: Windows10(64bit)
Memory: 8GB
HDD: 2TB
Image Processing: Brightness, Contrast, Sharpness, Zoom
Data Saving: Automatic or Manual Saving
Data Format: TIFF/BMP/JPEG (Plurally Selectable)
Display23.8inch Full Definitions×2 (Plurally Selectable)
Image Data Print: Automatic or Manual Printing
Safety Sensor: Hand Insertion Sensor
Dimensions: 1970(W)×810(D)×1735(H)mm
Weight: 700kg
Power Supply: AC90～120V 50/60Hz
Power Consumption: 0.8KVA
X-ray Leakage: 1μSV/h or less
Operating Temperature: 5～35℃
Operating Humidity: 20～80％RH (No condensation)
Standard Accessories: Instruction Manual, Test Piece
Option:Touch Panel, PC Printer (Selectable), label Printer, Roller Conveyor, Electric Conveyor (Put/Carry Out), Monitor Stand, Putting Guide, UPS, Barcode Reader
