Time measurement: 12 channels inherent opening (closing) time
Different periods in the opening (closing) phase
The difference between opening (closing) phases in different periods
Closing (opening) bounce time (bounce times)
Different period test range: 0.10ms~99ms, resolution: 0.01ms;
Internal trigger test range: 0.10ms~999ms, resolution: 0.01ms,
1000ms~9999ms, resolution: 0.1ms, 10000ms~200000ms resolution: 1ms.
External trigger test range: 0.01ms~200s
Accuracy rate within 1000ms: 0.05%±1 word
Speed measureme: just opening (just closing) speed
Average speed in a specified time period (stroke period or angle period)
Speed measurement range: 1mm sensor 0.01~25.00m/s,
0.1mm sensor 0.001~2.50m/s
345° angle sensor 0.01~25.00m/s,
Laser sensor 0.01~15.00m/s.
Stroke measurement: Travel of moving contact (travel)
Contact stroke (open distance)
Over travel
Overshoot or rebound stroke
Measuring range: linear sensor: 50mm, measuring range: 0-50mm, resolution :0.1mm.
Optional 100-1000mm linear sensor of any length.
Encoder: 345° Rotate sensor, measurement
range: 0-1000mm, resolution :0.1о.
Current resistance range: the maximum current 30 A, resolution: 0.01 A, 1000 Ω resistance, resolution: 0.01 Ω.
Instrument power supply: AC 220V ± 10%; 50 hz plus or minus 10%
Dc power output: continuously adjustable DC20 ~ 270V, DC220V≤20A (short time), Power: 4400W.
External trigger voltage: AC/DC10-300V, current ≤120A
Disconnecting switch measurement range: Voltage output DC20~270V(adjustable)
Current output time: 0.01~10 s (settable)
Fracture signal maximum acquisition time: 10s
Measurable fracture closing, separation time, three-phase a synchronism , bounce time and frequency .
Mainframe volume: 360×260×170mm
Operating environment: -20℃~+50℃
Relative humidity: ≤90%
