Light source: semiconductor laser
Particle size range: 0.8μm~600μm (according to ACFTD calibration 1~100μm or ISO MTD calibration 4~70μm(c) calibration)
Detection channels: 8~64 channels are optional (factory default 64), the particle size can be set arbitrarily
Sensitivity: 0.8μm (ISO4402) or 3μm (c) (GB/T18854, ISO11171)
Resolution: <10% (GB/T18854, ISO11171)
Repeatability: RSD<2%: RSD<2%
Sample detection viscosity: ≤650cSt (too high viscosity can be tested with heating or dilution method)
Sampling volume: 0.2~6000mL, interval 0.1mL
Sampling accuracy: better than ±0.5%
Sampling speed: 5 ~80mL/min
Barometric chamber: Positive and negative pressure chamber device to realize sample degassing and high-viscosity sample detection
The maximum vacuum of the barometric chamber: -0.08Mpa
The maximum positive pressure of the barometric chamber: 0.8 Mpa
Maximum particle concentration: 12000~40000 grains/mL
Temperature (paid option): collection range: 1~100°C; collection accuracy: 1°C
Water activity (paid option): collection range: 1~100%RH; collection accuracy: 1%RH
Moisture content (paid option): collection range: 1~360ppm; collection accuracy: 1ppm
Test sample temperature: 0℃～80℃
Working temperature: -20℃～60℃
Storage temperature: -30℃～80℃
Power supply: 110~245V AC, 50/60Hz, 70W
Host size: 340mm×410mm×650mm
Air pump size: 180mm×160mm×220mm
Net weight of host: ≥23kg Net weight of air pump: ≥5.5kg
