Test item range:
+ Open/ Short (os): 200Ω~50KΩ
+ Conductance (Cond.): 10mΩ~50Ω
+ Resistance (R): 0.1Ω~1MΩ
+ Capacitance (C): 10pF~1000uF
+ Zener (D): 0~10V
+ Dc Insulation (Is.): 1MΩ~1000MΩ
+ Ac Hipot (IL): 0.01mA~5mA
+ Arcing: 0~8 (0, off)
+ Intermittent Conductance (Int.cond.): 10mΩ~50Ω
+ Intermittent Open/Short (Int.os): 200Ω~50KΩ
+ High Speed Intermittent (Int.open): 0.4ms
Test information:
+ Output Rating: 5 VDC, 20mA max
+ DC Hipot/ insulation 5~1500V
+ AC Hipot/ 50~1000V (50V Resolution)
Test mode:
+ NORMAL/ S.SIDE/ S.STEP
+ Rated current & voltage analysis
Communication interface: Handler/ Rs232/ Print/ USB
Measurement& scanning Mode:
+ Series/ Parallel
+ Auto/Short Switchable
Decision mode: Pass /fail (LED); Speaker
Lock Mode: Standard lock/ Password lock
Starting mode: Auto/ Manual/ Continuous/ External
Memory: 1024KB
Comprehensive information:
+ Power Input: 220V±10% 60Hz (Option 110V 50Hz)
+ Power consumption: 100W
+ Temp.: -10°C~35°C
+ Humidity : RH≤75%
+ Size: 425*190*350 (64p or 128P)/ 425*240*350 (256P)
+ Weight: 13kg(64p)/ 14kg(128p)/ 18kg(256p)
+ Display: 320*240 LED
