Input Voltage AC: AC, 47~63Hz, 220V, ±10%
Output Rating: AC:5KV, 12mA
Output Frequency: 50Hz/60Hz ±0.1% (User selectable)
Output Waveform: Sine Wave, THD: < 2% at 300Vrms or higher voltage (Resistive Load), Crest Factor = 1.3~1.5
AC Current, mA (Max. Min.):
+ Range: 0.01~12mA
+ Resolution: 0.01mA/Step; Accuracy: ±2% Setting + 2Counts)
DC Output Rating: DC:6kV, 5mA
Output Ripple: <5% 6kV/5mA At Resistive load
DC Current, mA (Max. Min.):
+ Range: 0.01~5mA
+ Accuracy: 0.01mA/Step
+ Accuracy: ±(2% setting+2Counts)
AC/DC Setting :
+ AC 5KV; DC 6KV
+ Accuracy: ±(2% setting+5V)
Voltage ratio:±(1% Setting+5V) No load to full load
Ramp Up Time, second: Range: 0.1~999.9s, 0.1s/Step
Test time: Range: 0.1~999.9s, 0.1s/Step 0= Continuous
Arc Detection: The range is from 1~9 ( 9 is the most sensitive) 0=off
Voltmeter/ Ammeter
+ Range: 0~5/6KV, 0~12/5mA
+ Resolution: 0.01kV/Step; 0.001mA/Step
+ Accuracy:±(2% of reading +2Count)
Auto Discharge: Time at 200ms max. Capacitance
At 0.2uF; Input≤1kV
At 0.1uF; Input ≤2kV
At 0.05uF; Input ≤4kV
At 0.04uF; Input≤5kV
At 0.015uF; Input≤6kV
DC Voltage: 1KV
Insulation Range: 1M~9999M
Power: 110V/220V; Input±10%
Temp.: -10~35°C
Humidity: RH≤75%
Power consumption: Max 100W
Weight: ≈11kg
Size: 190*290*390mm
