Measurement method: Galvanic cell method
Measuring range
- Dissolved oxygen: 0mg/L to 20mg/L, 0.01 mg/L resolution
- Saturation 0% to 200%, 1% resolution
- Temperature 0℃ to 40℃, 0.1℃ resolution
Repeatability: Within ±0.5% of the full scale (by equivalent input)
Linearity: Within ±0.5% of the full scale (by equivalent input)
Tranmission output: 4-20mA DC, input/output isolated type; Maximum load resistance 900Ω
Transmission output range: freely selectable within the measurement range
Power supply: 100-240VAC; 50/60Hz 10VA (max.)
Temperature compensation range:0℃ to 40℃
Ambient temperature: −5℃ to 45℃
External dimensions: 48 (W) mm × 96 (H) mm × 115 (D) mm
Mass: Approx. 400 g
Compatible sensors:
- Sensor: 5400, 5405
- Probe: DP-100
Regulatory certification: CE marking, FCC rules
