Measurement Range: 0-50mm
Accuracy: ≤3um
Minimum: 1μm
Measurement Speed: Maximum 5000mm/s
Force: 1.0-1.5N
External Output: Data Interface、USB
Display: 7 Bit Liquid Crystal Display Device
Probe: Spherical Probe, Flat Probe, Needle Probe
Unit: mm、inch( Convertible )
Operating Environment: Temperature：0-40°C Humidity：20-80%
Measuring Table: 130x130mm Ceramic
Power Adapter: Input：AC100-240V50/60HZ Output：DC5V/1A
Standard Accessories: Ceramic Table，Spherical Probe, Flat Probe, Needle Probe
Optional Accessories: Special-shaped Probe, Mobile power supply, Low Force Measuring Device
Dimension: 200×138×397mm
Weight: 11.6kg
Production Feature：
Accuracy≤3um, Resolution 1um
Height、Depth、Thickness、Flatness Measurement
Steps and Deep Hole Measuring
Reset from Anywhere
MAX, MIN, MAX-MIN Measurement
Replaceable Probe
7 Bit Liquid Crystal Display Device
Wired Data Output
Optional Mobile Power Supply
High Accuracy Ceramic Measuring Table
