Loading Force:
N: 612.9, 980.7, 1226, 1839, 2452, 4903, 7355, 9807, 14710, 29420
kgf: 62.5, 100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000
Data Transfer: Bluetooth；RS232 is optional
Measuring Range: (8~650) HBW
Hardness Display: LCD Display
Hardness Conversion: HRC、HV、HBS、HBW、HK、HRA、HRD、HR15N、HR30N、 HR45N、HS、HRF、HR15T、HR30T、HR45T、HRB
Magnification of Eyepiece: 20x Mechanic Microscope
Max.height of Specimen: 225mm
Instrument Throat: 135mm
Power supply: AC220V/50Hz；110V/60Hz
Conversion Standard: ASTM、DIN
Languages: Chinese, English, German, Portuguese, Turkish, Czech, Korean
Dimension: 545 x235 x755mm
Gross/Net Weight: 160kg/130kg
Executive StandardGB/T4340、JIS Z2245、ASTM—E92、ISO6507
Accuracy of Brinell Hardness Testing:
Hardness Range:
HBW≤ 125: Max. Tolerance:≤± 3.5％; Repetition: ≤ 3.5％
125＜HBW≤225: Max. Tolerance: ≤± 2.5％; Repetition≤ 3.0％
HBW＞ 225: Max. Tolerance: ≤± 2.0％: Repetition≤ 2.5％
Standard Delivery:
Instrument Main Body
20x Mechanic Microscope
Hardness Block HBW/3000/10
Hardness Block HBW/750/05
Ø10mm Ball Indenter
Ø5mm Ball Indenter
Ø2.5mm Ball Indenter
Ø 200mm Flat Anvil
Ø 60mm Flat Anvil
Ø 40mm V-shape Anvil
Power Cable
Accessories Box
Level Screw
Anti-dust Cover
Instrument Manual/ Qualified Certificate
