DC Voltage:
200.0mV(200Vrms)/ 2000mV, 20.00V(500V DC/AC); ±(0.5%rdg+2dgt)
200.0V/ 500V ; 500V DC/AC; ±(0.5%rdg+4dgt)
AC voltage: 200.0V/ 500V; ±(1.2%rdg+10dgt); > 1MΩ; 500V DC/AC
DC current:
2000ΩA; ±(1.2%rdg+2dgt); Fast Fuse 200mA / 600V
200.0mA; ±(1.5%rdg+2dgt); Fast Fuse 200mA / 600V
Resistance: 200.0Ω- 200.0kΩ; ±(0.8%rdg+4dgt); 250Vrms < 15sec
2000kΩ, ±(1.5%rdg+2dgt), 250Vrms < 15sec
Battery Test: 9V; ±(1.2%rdg+2dgt); 250Vrms < 15sec
Display: LCD, 3 ½ dgt, 2000 points plus sign and decimal point ; Automatic polarity indication; “OL” overrange indication
Features: Data HOLD
Low battery indication: "BAT" appears when the battery voltage is low
Max altitude: 2000m
Pollution degree: 2
Insulation: double insulation
Power supply: 1x12V battery type MS21 / MN21; Protection fuse: fast 200mA/600V, 5x20mm
Dimensions: 105(L) x 50(W) x 25(H) mm
Weight (included battery): 100g
Accessories provided:
Pair of Leads KIT4000A
Batteries and user manual
