1. IMAGING PERFORMANCE
Detector type: UFPA
Spectral range: 8 ÷14μm
Risolution / Pxl size: 160x120 pxl / 25μm
Thermal sensitivity: <0.1 °C @ 30°C
Field of View (FOV): 29.8° x 22.6° (7.5mm lens)
Minimum focal distance: 0.2m
IFOV (@1m): 3.33mrad
Focusing: Manual on lens
Image frequency: 50Hz
Color palettes: 8 (Standard) + 10 (Customized)
Integrated camera: CMOS sensor 640x480pxl, FOV 62.3°
2. IMAGING / IR VIDEO DISPLAY
Display type: 3.5” TFT color, capacitive touch-screen, high brightness
Infra PiP Fusion: IR image inside visible & Visible image inside IR
IR Video: Recording and saving on micro SD card MPEG4 format
Video output: PAL / NTSC
Electronic zoom: x1 ÷ x20 in continuous way
Image rotation: 0° ÷ 360° in step of 1°
3. MEASUREMENT
Temperature range: -20°C ÷ 400°C
Measurement unit: °C, °F, °K
Accuracy: ±2%rdg or ±2°C
Measurement cursors: 3 (selection temperature MIN, MAX, Customized position on image)
Laser pointer Class: 2 according with IEC 60825-1
Built-in illuminator: White light LED
Measurement modes: Automatic / Manual / Histogram
Emissivity correction: 0.01 ÷ 1.00 + internal table with common materials
Measurement features: Automatic correction based on distance, relative humidity, atmospheric temperature, reflexed temperature, offset
Advanced analysis Spots: (max3), Lines (max 2), Areas (max 2), Isotherm
Alarm on temperature: Associated to measurements Spots
4. IMAGE STORAGE AND PC INTERFACE
Memory: Micro SD card 8GB
File format: JPEG standard
Memory size: > 2000 images
Voice annotation: 60 s / image
Textual annotation: With internal virtual keyboard
PC interface: USB 2.0 (for video and image transfer)
5. POWER SYSTEM
Battery type: Rechargeable Li-ION, 7,4V 2700mAh
Charging system: In camera or in base charger
Battery life: 4.5 hours of continuous use
External power: External adapter 100/240VAC (50/60Hz)/12VDC
Drop test: 2m
Dimensions (L x W x H): 243 x 103 x 160mm
Weight(battery included): 0.92kg
Accessories provided:
SSHIELD7X
TRIPO7X
ISO9000 calibration certificate
Cavo micro USB per collegamento PC
User manual on CD-ROM and quick guide
Micro SD Card 4GB
Video cable
Recharging base for battery BAT7X
Headset with microphone
Rechargeable Battery 2X BAT7X
Optics 7.5 mm f/1.0
Case VA6070
Charger A007X
THTLINK
