Specifications
Instrument Specifications | |
Display Type | 2.4" color OLED, 320X240 pixels, contrast 10,000:1 |
Operating Principle | Pulse echo with dual element transducers |
Measuring Range | 0.60mmto 508mm(0.025" to 20.00"), depending on material, probe and surface condition |
MeasuringResolution | Selectable 0.01mm, 0.1mm(selectable 0.001", 0.01") |
Units | Inch or Millimeter |
Gain | Low, Medium or High for varying test conditions |
Display Mode | Normal, Minimum / Maximum capture, DIFF/RR% |
V-Path Correction | Automatic |
Update Rate | Selectable 4Hz, 8Hz, 16Hz |
MaterialVelocity Range | 500 to 9999m/s (0.0197 to 0.3937in/us) |
Languages | Selectable Chinese, English, Japanese |
Alarm Settings | Minimum and Maximum alarms. Range of 0.25 mm to 508 mm (0.010" to 20.00"). Dynamic waveform color change on alarm |
Power Requirements | 2 AA size batteries |
Operating Time | Approximately 40 hours |
Instrument Shut-off | Selectable ALWAYS ON or AUTO OFFafter 5, 10, 20 minutes of inactivity |
Operating Temperature | -10°Cto +50°C (+10°F to +120°F) |
Size | 153mmX 76mm X 37mm(H X W X D) |
Weight | 280gincluding batteries |
Data Logger Option Features | |
Capacity | 400 files, 100,000 readings |
File Structure | Grid file |
Rows X Columns | 21 X 12 |
CommunicationPort | USB 2.0 (Full Speed ) port |
Software | Data View PC software |
Standard Configurations | |
Thickness Gauge | 1 |
Probe | 1 |
Alkaline Battery | 2 |
Couplant | 1 |
Carrying Case | 1 |
Operation Manual | 1 |
USB Cable | 1(Only TG-4500DL) |
Software CD | 1(Only TG-4500DL) |
Optional Configurations | |
High-temperature Probe | Cast Iron Probe |
Small Probe | Mini Probe |
Probe Cable | Stepped Calibration Block |
Rubber Sheath | Storage Option(Only TG-4500DL) |
Features:
Color 320x240 Pixels Display
A-Scan Snapshot
Echo-Echo Mode(Thru Paint & Coatings)
Stores 100,000 Readings
Gain: Low, Medium or High for varying test conditions
Specifications
|
Instrument Specifications |
|
|
Display Type |
2.4" color OLED, 320X240 pixels, contrast 10,000:1 |
|
Operating Principle |
Pulse echo with dual element transducers |
|
Measuring Range |
0.60mmto 508mm(0.025" to 20.00"), depending on material, probe and surface condition |
|
MeasuringResolution |
Selectable 0.01mm, 0.1mm(selectable 0.001", 0.01") |
|
Units |
Inch or Millimeter |
|
Gain |
Low, Medium or High for varying test conditions |
|
Display Mode |
Normal, Minimum / Maximum capture, DIFF/RR% |
|
V-Path Correction |
Automatic |
|
Update Rate |
Selectable 4Hz, 8Hz, 16Hz |
|
MaterialVelocity Range |
500 to 9999m/s (0.0197 to 0.3937in/us) |
|
Languages |
Selectable Chinese, English, Japanese |
|
Alarm Settings |
Minimum and Maximum alarms. Range of 0.25 mm to 508 mm (0.010" to 20.00"). Dynamic waveform color change on alarm |
|
Power Requirements |
2 AA size batteries |
|
Operating Time |
Approximately 40 hours |
|
Instrument Shut-off |
Selectable ALWAYS ON or AUTO OFFafter 5, 10, 20 minutes of inactivity |
|
Operating Temperature |
-10°Cto +50°C (+10°F to +120°F) |
|
Size |
153mmX 76mm X 37mm(H X W X D) |
|
Weight |
280gincluding batteries |
|
Data Logger Option Features |
|
|
Capacity |
400 files, 100,000 readings |
|
File Structure |
Grid file |
|
Rows X Columns |
21 X 12 |
|
CommunicationPort |
USB 2.0 (Full Speed ) port |
|
Software |
Data View PC software |
|
Standard Configurations |
|
|
Thickness Gauge |
1 |
|
Probe |
1 |
|
Alkaline Battery |
2 |
|
Couplant |
1 |
|
Carrying Case |
1 |
|
Operation Manual |
1 |
|
USB Cable |
1(Only TG-4500DL) |
|
Software CD |
1(Only TG-4500DL) |
|
Optional Configurations |
|
|
High-temperature Probe |
Cast Iron Probe |
|
Small Probe |
Mini Probe |
|
Probe Cable |
Stepped Calibration Block |
|
Rubber Sheath |
Storage Option(Only TG-4500DL) |
