Channels: 8 channels and 8 probes (max)
Pulse Type: Negative square wave pluse(Adjustable pulse width)
Pulse Edge: <8ns
Pulse Width: 50～1000ns (10ns step)
Pulse Repetition Frequency: 100～1000Hz per channel (1Hz step)
Detecting Way: Hardware
Sampling Frequency: 100MHz/200MHz
Amplifier Bandwidth (-6dB): 0.5~5MHz,2~10MHz,4~15MHz,0.5~30MHz
Waveform Display Mode: RF wave, Full-wave rectified, Positive half-wave rectified, Negative half-wave rectified,FFT Spectrum
Velocity Range: 300～20000m/s
Echo Range: 5.12～10000μs
Time Base Delay: 0～1000μs
Trigger Type: Time(with 5ms step)or position coder (with 0.25mm step)
Equivalent Input Noise: 40×10-9V/√Hz
Attenuator Accuracy: < ±1dB/20dB
Blind Firing Pulse: < 2μs
Image Mode: A-scan,B-scan or TOFD image based on the instrument settings
Recording Method: The original data completely recorded, sampling depth of 4096 points
Scanning Length: 0.01~2 m adjustable one time, more than 1500 m continuously
Work Mode: Single/Multi-Channel Pulse-Echo method; Single/Multi-Channel TOFD method; Pulse-Echo and TOFD mixed mode
Data Analysis online : Multi-Channel A-scan waveform replay; Multi-channel data global image browse; Channel selection and details zoom observation; Defect length, depth, and the height of multi-channel parameters quantitative analysis
Data Analysis outline: Multi-channel A-scan waveform replay; Multi-channel data global image browse; Channel selection and details zoom observation; Defect length, depth, and the height of Multi-channel parameters quantitative analysis; synthetic aperture focusing technique(SAFT)
Detection Report: Generate detection report according to the National Standard 4730.10
Memory: 1GB (upgradable)
Flash (CF card): 4GB(upgradable)
Interface: LAN,VGA,USB2.0
Display Type: 6.5 " high-brightness and high-resolution1024 × 768 pixel TFT LCD with touch screen
Input: Touch screen, Front panel keypad, Multifunctional knob
Compatible Peripheral Equipment: USB Keyboard, Mouse, Printer,Monitor and Projector
Power Supply: 14.4V lithium batteries, 6.6AH, working time > 4 hours, with external 19V adapter
Dimensions: 277(L)×183(W)×72(H)mm(Including the battery)
Weight: 2.41kg(Including the battery)
