Specification
Withstand voltage test:
Output voltage:
Range:AC: 5kV; DC: 6kV
Resolution (d):0.001kV
Accuracy:±(2%+5d)
Test current:
Range:AC: 10mA; DC: 5mA
Resolution (d):AC: 0.001mA~0.01mA; DC: 0.1µA-0.01mA
Accuracy:±(2%+5d)
Insulation resistance test:
Output voltage:
Range:1kV
Resolution (d):0.001kV
Accuracy:±(1%+2d)
Test resistance:
Range:10GΩ
Resolution (d):0.001ΜΩ~0.01GΩ
Accuracy:
output voltage≥500V, test resistance 1ΜΩ-1GΩ: ±(5%+5d)
output voltage≥500V, test resistance 1GΩ-10GΩ: ±(10%+5d)
output voltage<500V, test resistance 0.1ΜΩ-1GΩ: ±(10%+50)
Discharge function:discharge after testing
Arc detection:1-9 level (AC/DC), factory default is 5
Time:
voltage rising time: 0.1s~999.9s;
voltage falling time: 0.1s~999.9s;
voltage testing time: 0.1s-999.9s
Interface:HANDLER interface, RS232C interface, USB interface
Operation environment:temperature: 10°C~40°C; relative humidity: ≤70%
Power supply:AC 110V/220V, 50Hz/60Hz
Dimension (LxWxH):450x270x130mm
Weight:9.2kg
Standard Delivery:
Main unit:1pc
High voltage test clip:2pcs
High voltage test rod:1pc
RS232 communication cable:1pc
■ 5-inch LCD touch screen display
■ Arc detection function
■ Electric shock protection function
■ 10 test files can be stored, each file can be edited with
16 test steps.
■ Standard communication interface to meet automation test requirements.
■ Applications: home appliance, transformer, electrical device, component.
