Range
High current mode:
Slow & medium speed test:
20mΩ ±(0.5%+3d)
200mΩ/ 2Ω/ 20Ω/ 200Ω/ 2kΩ/ 20kΩ/ 200kΩ ±(0.05%+1d)
2MΩ ±(0.5%+1d)
20MΩ ±(1%+3d)
Fast speed test:
20mΩ ±(0.5%+5d)
200mΩ/ 2Ω/ 20Ω/ 200Ω/ 2kΩ/ 20kΩ/ 200kΩ ±(0.1%+3d)
2MΩ ±(1%+3d)
20MΩ ±(2%+5d)
Low current mode*:
Slow, medium, fast speed test:
20mΩ ±(0.5%+5d)
200mΩ/ 2Ω/ 20Ω/ 200Ω/ 2kΩ/ 20kΩ/ 200kΩ ±(0.1%+3d)
2MΩ ±(1%+3d)
20MΩ ±(2%+5d)
Resolution
High current mode:
Slow & medium speed test:
0.01mΩ
0.01mΩ/ 0.001Ω/ 0.001Ω/ 0.01Ω/ 0.01Ω/ 0.01kΩ/ 0.1kΩ
0.0001MΩ
0.01MΩ
Fast speed test:
0.01mΩ
0.01mΩ/ 0.0001Ω/ 0.001Ω/ 0.01Ω/ 0.01Ω/ 0.0001kΩ/ 0.001kΩ/ 0.01kΩ
0.0001MΩ
0.01MΩ
Low current mode*:
Slow, medium, fast speed test:
0.01mΩ
0.01mΩ/ 0.0001Ω/ 0.001Ω/ 0.01Ω/ 0.01Ω/ 0.0001kΩ/ 0.001kΩ/ 0.01kΩ
0.0001MΩ
0.01MΩ
Range mode:auto range, manual range and nominal range
Test speed:slow: 3t/s, medium speed: 15t/s, fast: 30t/s
Trigger:internal trigger, manual trigger, remote trigger
Interface:Mini USB interface, compatible with SCPI command
Power supply:rechargeable lithium battery (operating time ≥ 8 hours), power adapter-powered
Dimension:130x210x38mm
Weight:700g
Standard Delivery:
Main unit:1pc
Power adapter: 1pc
Mini USB communication cable:1pc
Test clip:1pc
* When using the 2MΩ and 20MΩ ranges, it is recommended to select the high current mode.
