Specification
Parameters: Cs-Rs, Cs-D, Cp-Rp, Cp-D, Lp-Rp, Lp-Q, Ls-Rs, Ls-Q, G-B, R-X, Z-θrad, Z-θrad, DCR
Monitor parameters:Z, D, Q, θrad, θdeg, R, X, Y, B, Vac, lac, Δ, Δ%
Test frequency:10Hz~100kHz
Signal level: voltage: 10mV~2V; current: 100μA~20mA
DC bias: -2.5V~+2.5V
Source resistance: 30Ω, 50Ω, 100Ω
Range:auto range, manual range and nominal range, 9 levels of ranges
Maximum reading:main parameter: 999999; secondary parameter: 999999
Test speed: fast: 40 t/s; medium speed: 10 t/s; slow: 3 t/s
Comparator:11-level sorting, 9-4evel GD, 1-level NG, 1-4evel AUX
Interface:RS232 interface, RS485 interface, USB interface, HANDLER interface
Power supply: AC: 100V-240V, 50/60Hz
Dimension (LxWxH): 350x264x107mm
Weight:2.6kg
Standard Delivery:
Main unit:1pc
Kelvin clip lead:1pc
Test fixture:1pc
Short-circuit plate:1pc
■ 3.5-inch TFT LCD display
■ Basic accuracy: 0.05%
■ Auto level control
■ Calibration function: full-scale open circuit and short-circuit sweep frequency clear, three groups of users point frequency calibration.
■ List test: cyclic scanning of up to 10 groups of frequency or level is performed and the results are cornpared to the set values.
■ Comparator: 11-level sorting function, up to 999,999 measured parts can be counted.
