Specification
Measurement geometry:5 measurement angles (5 illumination sources, 1 receiver)
Measuring angle:45° receiver: 45as15°, 45as25°, 45as45, 45as75°, 45as110"
Lighting source:full spectrum LED light source with blue enhancement
Lamp life:5 years, 3 million times measurements
Spectrophotometric mode:concave grating
Sensor:256 image element double array CMOS image sensor
Wavelength range:400nm-700nm
Wavelength interval:10nm
Measurement range:0~600%
Semiband width:10nm
Measuring aperture:illuminant Ø23mm/sampling Ø12mm
Color space:CIE LAB, XYZ, Yxy, Lch, Bxy, DIN Lab99
Color difference formula:ΔΕ*ab, ΔΕ*94, ΔΕ*cmc (2: 1), ΔΕ*cmc (1: 1), ΔΕ*00, DINAE99, ΔΕ DIN6175
Other colorimetric index:flop index
Observer angle:2°/10°
Illuminant:D65, A, C, D50, D55, D75, F1, F2 (CWF), F3, F4, F5, F6, F7 (DLF), F8, F9, F10 (TPL5), F11 (TL84), F12 (TL83/U30)
Measuring time:approx 1 second for one angle, approx, 5 seconds for all angles
Repeatability:spectral reflectance: standard deviation within 0.08% chromaticity value: ΔE*ab 0.03 (when a white calibration plate is measured 30 times at 5 second intervals after white calibration)
Reproducibility:ΔE*<0.10, avg on the gray tile of BCRA tile set, ΔE*<0.25, avg on the color BCRA tile set
Spectrophotometric mode:0.2ΔE*00 (avg on reference series II BCRA tile set)
Trigger mode:pressure sensing, trigger, key trigger, software trigger
Measuring mode:single measurement, average measurement (1-99), continuous measurement (1~99)
Locating method:color camera preview
Power:Li-ion battery, 3.7V, 3200mAh, continuous test 6000 times within 8 hours of full charge
Display screen:3.5-inch TFT color LCD, capacitive touch screen
Interface:USB, bluetooth 5.0
Date storage:standard 1000 pcs, sample 4000 pcs
Calibration:built-in white board parameters, external white board, black light trap
Calibration interval:4 hours, 8 hours, 24 hours, startup calibration
Dimension:195X83X128mm
Weight:1kg
Standard delivery
Main unit:1pc
Black light trap:1pc
White board:1pc
Software and USB cable:1pc
Power adapter:1pc
Bluetooth receiver:1pc
- Adopt 5 illumination sources, 1 receiver to measure 5 measurement angles at the same time
- Touch screen can display all angle measurement results, more intuitive view of the comprehensive data
- Full spectrum illumination measurement is more professional to avoid spectrum loss
- Provide 6 color spaces, multiple observation light sources
- Using concave grating spectrophotometric technology, with higher resolution, makes color measurement more accurate
- Built-in color camera positioning, can accurately judge the object measured position, and improve the measurement efficiency and accuracy
- Multiple functions, the screen can display various data intuitively
