Application
Alloy analysis: Can be used for almost all alloys, including scrap metal, high temperature alloys, alloy steel, stainless steel, tool steel, chromium molybdenum steel, aluminum alloys, nickel alloys, titanium alloys, cobalt alloys, cupric alloys, precious metals, zinc alloys, anomalous alloys, au-zirconium alloys, mixed alloys, etc.
Material properties identification (PMI): Can be used for quality control in the metal fabrication and processing industry to analyze material composition and identify alloy grades for a wide range of materials including critical missing pieces, raw materials, and welded seams
Operative system: android
Touch panel: 5", 720x1280, Multi-Touch, adjustable brightness pulsed laser
Light source: 1535nm
Laser life: 1 billion times
Laser clas: class I
Detection limit: 0.05%
Repeatability: major element RSD<1%, nonmajor element RSD<5%
Analysis time: <5s
Work distance: fit to probe plane
Analysis improvement: no protective gas required, direct analysis in ambient air
View window material: sapphire
Memory: 16G
Data export format: PDF, xlxs (photos available)
Data transmission: USB, flash drive (type C)
Protection class: IP54
Battery: 3300mAh lithium battery
Work time:8h
Power: 10W
Operation temperature: -10-40°C
Dimension: 290×300×90mm
Weight: 1750g
STANDARD DELIVERY
Main unit: 1 pc
Battery: 2 pcs
Charger: 1 pc
Sanding paper: 20 pcs
Iron base calibration foils : 2 pcs
Aluminum base calibration foils : 2 pcs
Copper base calibration foils : 2 pcs
Wavelength base calibration foil: 1 pcs
■ LIBS is used to analyze elemental composition by focusing high-energy pulses onto the surface of a sample and generating a plasma after exciting the electrons in the outer layers of atoms
■ Widely used in metallurgy, casting, iron and steel, non-ferrous metals and scrap metal recycling industry, can be a variety of elements of the material rapid quantitative and qualitative analysis and alloy grade identification
■ Can accurately analyse light elements such as Al, Be, Mg, etc.
■ Direct analysis of solid samples is a powerful tool for rapid screening and is compatible with alloy samples of various shapes
■Radiation-free, faster, more accurate, eye-safe handheld spectrometer
■ Built-in grade database, you can create your own grade database
■ Lightweight and portable, long standby time, worry-free battery life
■IP54 dust/waterproof
