SPECIFICATION
Measuring range: 0~2000um
Resolution:0.1μm (range<100μm); 1μm (100μm range<1000μm); 0.01mm (1.00mmsranges 2mm)
Accuracy: ±(2um+3%L) L is measuring thickness in um
Measure interval: 0.5s
Calibration mode: zero calibration
Measuring mode: Fe, NFe, Fe/NFe
Minimum substrate thickness:
FE: 0.2mm
NFe: 0.05mm
Minimum measuring area: 25mm
Minimum radius of curvature workpieces:
Convex surface: 5mm
Concave surface: 25mm
Unit: um/mil
Power supply: 2x1.5V AA batteries
Dimension: 101x62x28mm
Probe dimension: 71x26x22mm
Weight: 114g
Main unit: 1pc
Standard delivery
Fe zero calibration plate: 1pc
Nfe zero calibration plate: 1pc
Standard foil (100um): 1pc
1.5V AA battery: 2 pcs
