Function: Wire measuring, Cut into length, Full stripping, Partial stripping, Middle strip, Length correction
Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass
Conductor cross-sections: 0.03-4 mm²
Cutting length ( L ): 0.1 - 999999 mm
Cutting length accuracy: 0.002 x L
Stripping length: Front (right) side - 50 mm [Full stripping], Rear (left) side - 30 mm [Full stripping]
Production rate: 4100 pcs/h by 100 mm wire length
Data library: 100 programs
Display: 4.3" color touchscreen, English / Chinese [Other languages on request]
Compatible peripherals: Wire prefeeder, robot arm, conveyor belt
Wire feeding: Metal roller [Urethane roller on request]
Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz
Air supply: 0.4 - 0.7 MPa (clean and dry air)
Dimensions: Machine - L 370 x W 400 x H 300 mm, Straightener - 150 mm
Weight: 22 KG
CE-Conformity: Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
• Thin lead wire, short stripping
• Wire range up top 4mm²
• Best price, good performance
• Touch screen, English display
• Best choice for low-budget customers
• No safety cover
