Measurement function
Measurement parameter: L-Q, C-D, R-Q, |Z|-Q
Basic accuracy: 0.1%
Equivalent circuit: Series ,parallel
Mathematical function: Absolute value deviation,△%
Range mode: Auto, Hold
Trigger mode: Internal, Manual, External
Measurement speed: Fast: 18, Med:8,Slow: 2.5 (time/second)
Calibration function: Open/Short full correction
Measurement terminal: 5-terminal
Display mode: Direct，Δ%，
Display: 192*64 LCD display
Measurement signal
Signal frequency: 100Hz,120Hz,1kHz,10kHz
Output impedance: 30 Ω, 100 Ω
Test level: 0.1Vrms, 0.3Vrms, 1Vrms
Measurement display range:
|Z|, R 0.0001 Ω —99.999 MΩ
C 0.01 pF —99999μF
L 0.01 μH —99999 H
D 0.0001 —9.9999
Q 0.0001 —9999.9
Δ% -999.99% —999.99%
Comparator and interface
Comparator: NG, P1, P2, P3, 4 Bins and Alarm mode setup
Interface: RS232C, Handler (option)
General Specifications
Operation Temperature And Humidity 0°C－40°C, ￡90%RH
Power supply:
voltage 99V－121V, 198V－242V
frequency 47.5Hz－63Hz
Power consumption: ≤20 VA
Volume (W×H×D): 270mm×130mm×290mm
Weight: about 3.5kg
