Test function: AC/DC/IR
Measure parameter:
AC: 0.05kV-5.00kV ±(2% rdg+5dgt)(50/60Hz optional)
DC: 0.05kV-6.00kV ±(2% rdg+5dgt)
Voltage regulation: ≤(1.0%+5V)(rated power)
Current test range:
AC: 0.000mA-12.00mA
DC: 0.000mA–5.00mA
Test accuracy: ± 2.0% rdg+5dgt
Discharge function: Automatic discharge after the test is over(DCW)
Insulation resistance test:
Output voltage: 0.05kV –1kV ±(2.0% rdg+8dgt)
Resistance test range: 0.1 MΩ-50GΩ
Resistance test accuracy:
500V-1000V:
0.1 MΩ-1GΩ: ±(5% rdg+2dgt)
1GΩ-10GΩ: ±(5% rdg+5dgt)
10GΩ-50GΩ: ±(10% rdg+2dgt)
50V-500V:
1MΩ-1GΩ: ±(5% rdg+2dgt)
Discharge function: Automatic discharge after the test is over
Arc Detection:
Measuring range:
AC: 0mA –15mA
DC: 0mA –10mA
Other function:
Voltage rise time: 0.1s –999.9s
Test time(AC/DC): 0.2s –999.9s
Voltage waiting time(IR): 0.2s –999.9s
Time precision: ±(1%+0.1s)
Display: 4.3’’ TFT
Port: PLC, RS232C, USB
Size: W280mm * H88mm * D380mm
Datasheet
Performance characteristics
￭ Three test functions are available: ACW, DCW, IR
￭ 480×272 dots, TFT-LCD display
￭ Output power: AC: 5kV/10mA; DC: 6kV/5mA
￭ Can carry out online test of 100 units at the same time
￭ 20 test steps can be stored, 4 test steps can be connected to the program memory step
￭ Fast communication speed, baud rate up to 19600
￭ Fast discharge and arc detection function
￭ Anti-high voltage electric shock function, the output can be interrupted immediately when the human body accidentally touches it
￭ The test of the power-on self-test function can be used to determine whether each test function is normal before the test.
￭ Front panel software input calibration
￭ Can set calibration time and warning time to remind users
￭ Built-in PLC Remote interface
￭ Keyboard lock function
￭ Security lock function
￭ Small size and light weight
￭ Application: computer peripheral equipment, home appliances, electrical products, communication products, OA products, lighting products, small home appliances, lighting equipment, electronic components, transformers, Motor, compressor, electric heating pipe, wire, cable, etc.
