Capacity: 2,5,10,20,50,100,200 kg, 500 kg
Force measurement accuracy: ± 1% of the indicated value
Display mode: LCD display in Chinese, film touch key (display force value and displacement parameter)
Unit switch: Kg, lb, N
Data sampling frequency: 200times/ SEC
Resolution of testing machine: the maximum load is 1/± 25,000 yards, the inside and outside are not classified, and the whole resolution is unchanged
Load sensors: Basic configuration: Pull and pressure sensors (maximum load)
Effective test width: 150mm
Effective drawing space: 650mm/800mm/1000mm
Test speed range: 50-300mm/min stepless speed regulation and 5-gear constant speed (special test speed can be customized according to customer requirements)
Displacement measurement accuracy: within ± 0.5% of the indicated value
Breakpoint ratio setting: 0 ~ 99%, users can set the appropriate break down time according to different materials
Test bench safety device: up and down travel limit device
Overload protection: when the maximum load exceeds 10%, the machine will be protected automatically
Fixture configuration: One set of drawing fixture
Host size: 450×500×1400mm
Main engine weight: about 60 Kg
Power supply: 220 v / 50 hz
Basic configuration
One host for each host
One set of standard fixtures
