Application
Scribing, Drilling
Surface treatment
Sheet metal cutting, Welding
Marking on fly
Metal surface processing, Peeling coating
Specification
M²: <1.4
Armored Cable Length (m): 2
Nominal Average Output Power (W): >20
Maximum Pulse Energy (mJ): 0.8
Pulse Repetition Rate Range (kHz): 1 ~ 4000
Pulse Duration (ns): 2 ~ 350
Output Power Stability (%): <5
Cooling Method: Air Cooled
Supply DC Voltage (VDC) (V): 24
Maximum Power Consumption (W): <110
Environmental Supply Current (A): >5
Central Emission Wavelength (nm): 1064
Emission Bandwidth @3dB (nm): <15
Polarization Orientation: Random
Anti-high Reflection: Yes
Output Beam Diameter (mm): 7±0.5
Output Power Tuning Range (%): 0 ~ 100
Operation Temperature (℃): 0 ~ 40
Storage Temperature (℃): -10 ~ 60
Net Weight: 3.75 kg
Size(L×W×H): 245 × 200 × 65 mm
JPT M7 series high power pulsed fiber lasers make use of master oscillator power amplifier (MOPA) configuration, and show excellent laser performance as well as high level of temporal pulse shaping controllability. As compared to the Q-switching technology, the pulse repetition frequency (PRF) and pulse width can be controlled independently in MOPA configuration, through adjusting different combination of the above parameters, the peak power of laser can be well maintained. And enable JPT laser suitable for more material processing which Q-switch limited. The higher output power makes its advantages especially in high speed marking applications
