JSEDM EMB-1360 CNC Milling (5~15 HP)
Manufacturer: JSEDM Model: EMB-1360 Guarantee: 12 Month - Request a Quotation
- Contact
Longitudinal - X axis: 1300 mm
Rapid Traverse Rate: 10000 mm/min
Cross- Y axis: 600 mm
Ball Screw: Ø40mm x 10P x C5 mm
Vertical - Z axis: 600 / 700, 800(Opt.) mm
Spindle Motor:
- 5 HP / 7.5 HP + inverter(BH)
- 10 HP / 15 HP + inverter(VF)
- 10 HP / 2P + 4P (G)
Table size: 1702 x 510 mm
X, Y, Z axis Servo Motor: 1.3 / 2 (Opt.) kw
T-slot: 18 x #5 mm
Coolant Pump Motor: 1/4 HP
Max. loading capacity: 1200 kgs
Semi Splash Safety Guard: Yes
Milling Head type: BH / VF / G
Full Splash Guard: No
Spindle Taper:
- NT#40 / BT#40(BH)
- NT#50 / BT #50(VF/G)
Floor Clothed Curtain Splash Guard: Yes (Opt.)
Spindle Speed:
- 60-4000 (BL / BH)
- 3-step 60-3000(VF) / 6-step /12-kinds 125-1100 rpm (G)
Machine Overall Height: 2580 / 2680, 2780(Opt.) mm
Spindle Quill Rate: 127 / 150(Opt.)(BL) / 140(BH) mm
Machine Floor Space: 3900 x 3300 mm
Swivel: Left & Right ±45°(BL/BH)
Machine Net Weight: 5000 kgs
Datasheet
