Performance Data Temperature
Temperature range 12°C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 2.0
Temperature fluctuation at 150 °C [± K]: 0.6
Heating-up time to 150 °C [min]: 25
Recovery time after 30 seconds door open at 150 °C [min]: 6
Electrical data
Rated Voltage [V]: 400
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 4.5
Unit fuse [A]: 3x16
Phase (Nominal voltage) [ph]: 3~
Outer dimensions
Width net [mm]: 1165
Height net [mm]: 1590
Depth net [mm]: 870
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Doors
Unit doors: 2
Internal Dimensions
Width [mm]: 1000
Height [mm]: 1300
Depth [mm]: 570
Further Dimension
Interior volume [L]: 741
Net weight of the unit (empty) [kg]: 162
Permitted load [kg]: 315
Load per rack [kg]: 45
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 800
Sound-pressure level [dB(A)]: 43
Fixtures
Number of shelves (std./max.): 2 / 16
