Sealing specification
Sealing bars: "2 NIPTEF, 5 x 50 / 10 x 50"
Specimen width [mm]: max. 40
Specimen thickness [mm]: max. 1
Sealing time [s]: 0,1 … 20
Sealing temperature [°C]: 21 - 260
Sealing pressure [N/mm2]: 0.05 … 2.0
Pealing specification
Cooling time [s]: 0.1 …. 999
Peeling speed [mm/s]: 8 … 600
Peeling control Servomotor
Specimen length [mm]: min. 250
Hot tack force measurement
Measurement range [N]: 0 … 45 (optional 450)
Sampling speed [mm/s]: max. 20
ADC resolution: 12 bit
Dimension
Width [mm]: 220
Height [mm]: 287
Depth [mm]: 556
Weight [kg]: approx. 14
Connections
Rated Voltage [V]: 90 - 264
Power frequency [Hz]: 50/60
Nominal power [kW]: 0.15
Phase (Nominal voltage) [ph]: 1~
Compressed Air [bar]: 6 - 8
