Performance Data Temperature
Temperature range (max. 28°C below ambient temperature) [°C]: 0…+70
Temperature variation at 37 °C [± K]: 0.1
Temperature fluctuation at 37 °C [± K]: 0.1
Recovery time after 30 seconds door open at 37 °C [min]: 4
Electrical data
Rated Voltage [V]: 200…230
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 0.9
Unit fuse [A]: 16
Phase (Nominal voltage) [ph]: 1~
Outer dimensions
Width net [mm]: 925
Height net [mm]: 1461
Depth net [mm]: 796
Wall clearance back [mm]: 100
Wall clearance sidewise [mm]: 100
Doors
Inner doors: 1
Unit doors: 1
Internal Dimensions
Width [mm]: 650
Height [mm]: 785
Depth [mm]: 485
Further Dimension
Interior volume [L]: 247
Net weight of the unit (empty) [kg]: 152
permitted load [kg]: 100
Load per rack [kg]: 30
Environment-specific data
Energy consumption at 4 °C [Wh/h]: 100
Energy consumption at 37 °C [Wh/h]: 65
Sound-pressure level [dB(A)]: 43
Fixtures
Number of shelves (std./max.): 2 / 9
