MAXIMUM POWER: 195W
LOAD REGULATION:
Voltage: ≤0.02% + 4mV
Current: ≤0.2% + 3mA
LINE REGULATION:
Voltage: ≤0.02% + 4mV
Current: ≤0.2% + 3mA
RIPPLE AND NOISE (20Hz–20MHz):
Voltage: ≤1mVrms/≤5mVp-p
Current: ≤6mArms
SETTING RESOLUTION:
Voltage: 10mV
Current: 1mA
SETTING ACCURACY:
Voltage: ≤0.06% + 20mV
Current: ≤0.2% + 10mA
READBACK RESOLUTION:
Voltage: 10mV
Current: 1mA
READBACK ACCURACY:
Voltage: ≤0.06% + 20mV
Current: ≤0.2% + 10mA
MEMORY: 30 setup memory locations.
OUTPUT TIMER RANGE: 0.1s to 99999.9s.
DISPLAY: Vacuum fluorescent display.
CONNECTIONS:
Front: Power output jacks: 3-sets, safety-shrouded
banana jacks.
Rear: DB9 connector for remote control,
OVERTEMPERATURE PROTECTION: If the internal
temperature of the supply exceeds 85°C, the supply will
automatically turn off.
EMC COMPLIANCE: Conforms to European Union EMC
Directive.
SAFETY COMPLIANCE: Conforms to European Union Low
Voltage Directive.
POWER LINE RATINGS: 110VAC/230VAC ±10%.
POWER LINE FREQUENCY: 47Hz–63Hz.
MAXIMUM POWER CONSUMPTION: 750VA.
OPERATING ENVIRONMENT: 0° to 40°C, 5% to 80% relative humidity at up to 40°C.
STORAGE ENVIRONMENT: –20° to 70°C, 5% to 80%
relative humidity up to 40°C, and 5% to 60% relative
humidity from 40° to 70°C.
PHYSICAL CHARACTERISTICS
Height: 88.2 mm ( 3.5 in)
Width: 214.5 mm ( 8.5 in)
Depth: 354.6 mm (14 in)
Net Weight: 7.10kg (15.7 lbs.).
Shipping Weight: 9.40kg (20.7 lbs.).
TekSmartLab™ Solution:
TekSmartLab™ is the industry first network-based lab instrument management solution for quickly setting up and efficiently managing basic electronics engineering laboratories at colleges and universities. It supports up to 400 instruments (100 test benches) on a single platform. It automatically records and displays instrument asset information, providing laboratory administration with better information for classroom scheduling or making decisions on energy consumption and lab equipment investments. Instead of using a USB thumb drive, students can retrieve test results wirelessly with their smart devices. The centralized control of instruments enabled by the TekSmartLab solution dramatically improves the classroom and lab experience for students, instructors and lab managers.
Solution : 4 in 1 Package
- Digital Scope TBS1102B-EDU
- Signal Generator AFG1022
- Power Supply 2231A-30-3
- Digital Multimeter 2110-220
- USB Adapter w/USB Cable 2231A-001
- TekSmartLab™ * TBX3000A , TSL3000B* (Software)
