Display resolution
0.1µm for less than 100μm, 1μm for 100μm or more (when displayed in μm)
0.01mm for less than 10mm, 0.1mm for 10mm or more (when displayed in mm)
Display: Digital (2.7 inch full color LCD)
Data memory: 50,000 items
Number of application memories: 50 (per probe)
External output: USB-C
Power supply: 1.5V (AA alkaline battery*1) ×4
Power consumption: Max. 1W
Battery life: 70 hours*2
Operating ambient temperature: 0 to 40°C, 85% RH or less (no condensation)
Additional functions: Substrate calibration, foil calibration, application selection, upper/lower limit setting, unit switching, measurement mode switching, language switching, statistics calculation (block/group), data memory, auto power off, backlight, date and time setting, display switching, etc.
Dimensions and weight: 70 (W)×155 (D)×35 (H) mm, 0.2 kg
Accessories: Iron substrate (for Fe probe), Aluminium substrate (for NFe probe), Calibration foils x 4 (10, 100, 500, 1000μm),Battery 1.5V (AA alkaline) x 4, Probe adapter, Carrying pouch, Strap, USB cable (Type-C), Connector cover, List of compatible probes & optional calibration foils, Operating Manual
Options: Various Fe/NFe probes (required option), Calibration foils (thickness other than accessories), Measuring Stand LW-990 for coating thickness tester, Soft carrying case, Bluetooth communication dongle VZC76, Calibration (calibration certificate, calibration record, traceability flow chart)
PC software (LDL Export): ✓
Mobile app (LDL Mobile): ×
