Power Capacity [kVA]: 75
Rated Current [A]: 113
Rated Voltage [V]: 220
Frequency[Hz]: 45-65
Phase: 3φ4W
Voltage Range [V]: 5-345
Input Characteristics:
Phase: 3φ3W＋PE
Voltage: 380V±15%
Frequency: 50Hz±5Hz
Output Characteristics:
Voltage:
Waveform: sinusoidal wave
Precision: ±0.5%•FS (linear load)
Setting Resolution: 0.1V
Display resolution: 0.1V
Load regulation: 0.2%•FS
THD: ≤1% (linear load)
Response time: ≤2ms (10%-90%) (Frequency changes at the same time.)
Current:
Precision: ±1%•FS (linear load)
Display resolution: 0.1A
Frequency:
Precision: ±0.01Hz
Display resolution: 0.01Hz
Setting resolution: 0.01Hz
Phase:
Adjustment step length: 0.1°
Adjustment range: 360°
Communication & Interfaces:
Touch Screen: LCD
Remote Comms: RS485/LAN
Others: Emergency stop/Fault signal
Safety & Ambient Conditions:
Insulation Resistance: ≥20MΩ (500Vdc)
Withstand Voltage: 2000Vdc (60s, no arcing/breakdown)
Ground Resistance: ≤0.1Ω
Protection Level: IP21 (indoor)
Cooling: Fan cooling
Ambient Temperature: -10~40℃
Humidity: 0-90%RH (Non-condensing at 25℃)
Altitude: ≤2000m
