Frequency parameters / range
Frequency range: 9 kHz~2.0 GHz
Resolution: 0.001 Hz
Phase resolution: 0.1 deg
Settling time: 20 μs (Typical); 200 μs (Max)
Frequency update rate; List/Sweep mode: 400 μs (Time from receipt of SCPI command firmware)
Total jitter: 68 fs RMS (10 Hz to 1 MHz BW)
Reference frequency input: 8 MHz~200 MHz (User programmable)
Reference input level: -5 dBm (min); 0 dBm (Typical); +13 dBm (Max)
Lock Range: max +/- 1.0 ppm
Reference input impedance: 50 Ω
Internal reference frequency output: 10 MHz
Initial accuracy of internal reference: max ± 40 ppb (Calibrated at 23 ± 3 °C at the time of calibration)
Temperature stability (0 to 50 °C): max ±100 ppb
Aging 1st year: 0.5 ppm
Aging per day (after 30 days of operations): max 5 ppb
Warm-Up time: 5 min
Output of internal reference: +0 dBm, 50 Ω
