Measuring range: X=1000mm,Y=2000mm,Z=800mm
Dimension: 2280X3095X 3080 mm
Work table loading: 2000Kg
Machine weight: 4800Kg
MPEe: ≤ 1.9+3L/1000 μm
MPEp: ≤ 1.9 μm
Scale Resolution: 0.1um
Max 3D Speed: 520mm/s
Max 3D Acceleration: 1200mm/s²
Environment Specifications
Room Required Specifications
Average Room Temperature: 18 - 22°C
Maximum Thermal Gradients: 2 °C/day, 1°C/hour, 1°C/meter surrounding the machine.
Humidity: 40% to 70%
Air Supply System
Min. Air Pressure: 5.5bar(0.55MPa)
Air Consumption: 250NL/min
Electrical Requirements
Voltage: 220V ± 10%
Frequency: 50/60 Hz
Current: 15 A
Power: < 1100W
Earth resistance: < 4Ω
