E-Field Meter Ranges:
Manual selected.
± 20kV/m; ± 200kV/m und ± 1MV/m
Important ! Only in ths Mode the analog interface is switched on !
Max. Value:
Distance 1cm is switched on (for MK 023)
After pressing the switch the maximum pos. and neg. Measure Values are displayed (Walking Test). By pressing the switch again the values will be reset and starts again.
No zero drift
Therefore a zero adjustment is not needed before each measurement.
Measurement ranges:
distance 1cm: 0 to 10kV
distance 2cm: 0 to 20kV
distance 5cm: 0 to 50kV
distance 10cm: 0 to 100kV
distance 20cm: 0 to 200kV
Dimensions: 122mm x 70mm x 26mm ( L x W x H )
Weight: approx. 130 g (without battery)
Power supply: 9V Alkali battery IEC 6F22
Display:
2-line alphanumeric LC-display with 12 digits each
The measurement distance in cm will be displayed in the first line, the voltage potential will be indicated in volts in the second line.
Scope of delivery: EFM 023 with Volt-Meter-Set VMS022 and UAC 110 with KL-ReadOut Software for walking test conform to EN 63410 including the CP2 022 Set all in a stabil Aluminium Case
EFM 023
soft bag
9V Alkaline battery
grounding cable 1,5m
2 distance supports (2cm)
manual
certificate of calibration
The VMS 022 consists of:
Voltage measuring head MK023
Stand for secure installation of the EFM.
Conductive plastic case to hold all accessories
Hand electrode
5m silicone cable
UAC 110
