The ability of a lubricating oil to separate from water and resist emulsification is an important performance characteristic for applications involving water contamination and turbulence.

Specifications

- Conforms to the specifications of: ASTM D1401, D6074, D6158; ISO 6614; DIN 51599; FTM 791-3201; NF T 60-125

- Stirrer range: 1100-2000rpm

- Accuracy: ±1.0rpm

- Drive: 10hp (75W), high torque

- Bath temperature range: 25°C to 84°C

- Control stability: ±0.05°C

- Capacity: seven (7) 100mL graduated cylinders

- Construction: Clear polycarbonate tank 10"x11.25"x9.5" (25.5x28x24cm)

- Medium: Water or white technical oil

- Medium capacity: 15.15L (4 gal)

Electrical requirements: 220-240V 50/60 Hz, Single Phase, 12A

Dimensions

- lxwxh, in.(cm): 20.75x15.25x29.5 (52.7x38.75x74.9)

- Net weight: 83 lbs (37.6kg)

Shipping information:

- Shipping weight: 188 lbs (85.3kg)

- Dimensions: 34x27x40 in. (86.4x68.6x101.6cm)

Included accessories

- Seven 100mL cylinders

Additional accessories

- 332-002-018 Cylinder 100mL, graduated from 5 to 100mL with 1.0mL divisions

- 250-000-19F ASTM 19F Thermometer. Range: 120 to 134°F

- 250-000-19C ASTM 19C Thermometer. Range: 49 to 57°C

- 250-000-21F ASTM 21F Thermometer. Range: 174 to 188°F

- 250-000-21C ASTM 21C Thermometer. Range: 79 to 87°C

- K39252 PTFE Policeman

- K39251 Test Tube Rack
