Frequency Range : 1 – 500 Hz.
Maximum Stroke Options (peak-to-peak) : 2.5 in. (6.4 cm); 4 in. (10.2 cm);
Actuator Stall Force (at 3000 psi (207 bar)) : 4566 lbs. (20.3 kN)
Actuator Dynamic Force (at 3000 psi (207 bar)): 3044 lbs. (13.5 kN)
PHYSICAL
Table Sizes : 33.5 in. (85 cm) square; 60 in. (152 cm) square
Standard Hole Patterns : 6 in. grid, 3/8-16 Stainless Steel inserts; 15 cm grid, M10 x 1.5 Stainless Steel inserts
POWER REQUIREMENTS
System:200 – 460 VAC; 50, 60 Hz; Three Phase
Controls: 100 – 240 VAC; 50, 60 Hz.; Single Phase
FACILITY REQUIREMENTS
Cooling Water 6 gpm at 60⁰F (15.5⁰C at 23 L/min.)
Plant Air 80 psi (552 kPa), 1 scfm
For 1-G Supports (optional)
