Getter type: Combination of different alloy of Zr/V/Fe/Pd with 2 beds of purification
Gases purified: Noble gases
Impurities removed at room temperature: H2O, O2, CO, CO2, H2
Impurities removed when dual beds are heated: H2O, O2, CO, CO2, N2, NMHC, H2, CH4
Real time monitoring trace N2-H2O with ped available: yes
Impurity level at outlet: <1ppb
Flow: 2LPM nominal up to 20LPM maximum
Gas connections: 1/4” VCR
Recommended operating inlet pressure range: 50psig-200psig (345kpag-1379kpag)
Electrical supply: 220/240VAC 50/60Hz
Power consumption: At start up: 300 watts max, at normal operation: 200 watts max
Weight: 35lbs (15.9kgs)
Gas connection type : Compression
Supporting plate: Stainless Steel wall mount
Supporting plate valves config: : bypass & in & out valves compression 1/4”
