Operating principle: Magnetic induction or Eddy current
Measuring range (µm): 0~1250μm
Accuracy: ±[（1~3%)H+1]
Low range resolution (µm): 1μm
Min curvature of the min area (mm): Convex1.5 Concave20
Diameter of the min area (mm): Φ10
Critical thickness of substrate (mm): 0.5
Operating temperature: 0℃~40℃
Dampness: 20%~90%
Magnetic field: No strong magnetic field environment
Dimensions: 150×55.5×23mm
Power supply: AAA Alkaline battery
Weight: 120g
Standard configuration
Main unit, 5 specimens (50mm、100mm、200mm、500mm、1000mm)、4 AAA Batteries.
