Leeb 432 Surface roughness tester (Ra:0.005-16μm Rz:0.02-160μm; 0.001μm)
Manufacturer: Leeb Model: 432 Origin: China Guarantee: 12 Month - Request a Quotation
- Request a Quotation
- Contact
Roughness parameter: Ra、Ry、Rq、Rz、Rt、RSm、RS、Rp、Rv、R3z、RSk、Rmax、Rmr
Measuring range: Ra:0.005-16μm Rz:0.02-160μm
Resolution: 0.001μm
Cut-off lengths: 0.25mm / 0.8mm / 2.5mm
Evaluation length: 1.25mm / 4mm / 5mm
Accuracy: ≤±6%
Repeat ability: <6%
Sensor: Piezocrystal
Power supply: 3.7V Lithium-Ion battery
Operating temperature: 0 ºC -40 ºC
Weight: 440g
Dimensions: 119×47×65mm
Standard configuration
Main Unit,Standard sensor,Model for multi-standard groove,Power adapter
Optional Accessories: Measurement Platform, printer ,PC analysis software
