Measuring range
: Z axis (vertical) ±80μm/±160 µm（optional）
X axis (horizontal) 20mm
Resolution: 0．01μm/±20μm; 0．02μm/±40μm;
0．04μm/±80μm; 0．08μm/±160μm
Roughness parameters
Ra,Rz,Rq,Rt，
Rp,Rv,R3z,R3y,Rz(JIS),Rs,Rsk,Rsm,Rku,Rmr; Ry;
Rmax，Rc，RPc，Rk，Rpk，Rvk，Mr1，Mr2
Filtering methods: RC,PC-RC,Gauss,D-P
Sample length (lr): 0.25,0.8,2.5mm
Evaluation length（ln）: Ln= lr×n n=1~5
Indication error ≤ ±10%
Indication variability ≤ 6%
Memory 100 groups ( data and graphic)
Power supply 3300mAh Rechargeable Li-ion battery
Dimension (mm) Main body:64*53*160 Sensor dirver：23*27*115
Weight: About 380g (Main body)
Operation environment Temperature:- 20℃~40℃, Humidity:<90% RH
Storage/transportation environment Temperature:- 40℃~60℃, Humidity:<90% RH
