Measuring range: 0.0~3000μm
Resolution:
0.1μm: 0μm-99.9μm
1μm: 100μm-999μm
0.01mm: 1.00mm-3.00mm
Accuracy: ≤±(3%H+2μm), H is the standard value
Unit: μm / mil
Measuring interval: 0.5s
Minimum measuring area: Ø = 25mm
Minimum curvature: Convex:5mm / Concave:25mm
Minimum substrate thickness: Fe:0.2mm / NFe:0.05mm
Display:
Front: 128×48 dot matrix LCD
Top: 128×64 dot matrix OLED
Power supply: 2pcs of 1.5V AAA alkaline battery
Operation temperature range: -40℃-50℃
Storage temperature range: -50℃-60℃
Gauge size: 100*60*24mm
Weight(with battery): 80 g
