Mahr MarSurf GD 140 BG 22 Roughness Measuring Station (X 140mm, Z 600mm)

Resolution: Measuring range 1: 7.6 nm

                   Measuring range 2: 0.76 nm

Start of traversing length (in X):0 mm

Probe arm length: 45 mm (x1), 67.5 mm (x1,5), 90 mm (x2), 112.5 mm (x2,5), 135 mm (x3)

End of traversing length (in X):140 mm

600 mm Z-axis

With angular adjustment of the X-axis

Positioning speed: 0.02 – 200 mm/s (in X)

Guide deviation:0.07 µm / 20 mm,0.2 µm /  60 mm,0.4 µm / 140 mm

Measuring speed: Up to 10 mm/s

Measuring range:500 µm (±250 µm) for probe arm length 45 mm

                            1500 µm (±750 µm) for probe arm length 135 mm
